Sunflower oil waste takes out heavy metals

A membrane made from a waste by-product of sunflower oil manufacture can filter out heavy metals from contaminated water.
That is the finding of scientists from Nanyang Technological University (NTU) in Singapore, working in collaboration with ETH Zurich in Switzerland. The team discovered that proteins derived from the by-products of peanut or sunflower oil production can attract heavy metal ions very effectively.
In tests, they showed that this process of attraction, called adsorption, was able to purify contaminated water to a degree that meets international drinking standards. The researchers’ membrane has the potential to be a cheap, low-power, sustainable, and scalable method to decontaminate heavy metals from water.
"Our work puts heavy metal where it belongs – as a music genre and not a pollutant in drinking water."
The research was led by Professor Ali Miserez from the NTU schools of Materials Science & Engineering and Biological Sciences, and Professor Raffaele Mezzenga from the Department of Health Science & Technology at ETHZ.
Professor Miserez said, “Water pollution remains a major global issue in many parts of the world. Heavy metals represent a large group of water pollutants that can accumulate in the human body, causing cancer and mutagenic diseases.
"Current technologies to remove them are energy-intensive, requiring power to operate, or are highly selective in what they filter. Our protein-based membranes are created through a green and sustainable process, and require little to no power to run, making them viable for use throughout the world and especially in less developed countries."
Oilseed water filters
The production of commercial household vegetable oils generates waste by-products called oilseed meals. These are the protein-rich leftovers that remain after the oil has been extracted from the raw plant.
The NTU-led research team used the oilseed meals from two common vegetable oils, sunflower and peanut oils. After extracting the proteins from oilseed meals, the team turned them into nano-sized protein amyloid fibrils, which are rope-like structures made of tightly-wound proteins.
These protein fibrils are drawn to heavy metals and act like a molecular sieve, trapping heavy metal ions as they pass by. A kilogram of oilseed meal produces about 160g of protein.
The paper’s first author, NTU PhD student Soon Wei Long, said, “Protein-rich sunflower and peanut meals are low-cost raw materials, from which protein can be extracted, isolated, and self-assembled into functional amyloid fibrils for heavy metal removal. This is the first time amyloid fibrils have been obtained from sunflower and peanut proteins.”

The researchers combined the extracted amyloid fibrils with activated carbon – a commonly-used filtration material – to form a hybrid membrane. They tested their membranes on three common heavy metal pollutants - platinum, chromium and lead.
As contaminated water flows through the membrane, the heavy metal ions adsorb onto the surface of the amyloid fibrils. The high surface-to-volume ratio of amyloid fibrils makes them efficient in adsorbing a large amount of heavy metals.
The team found that their membranes filtered up to 99.89% of heavy metals. Among the three metals tested, the filter was most effective for lead and platinum, followed by chromium.
“The filter can be used to filter any sorts of heavy metals, and also organic pollutants like PFAS (perfluoroalkyl and polyfluoroalkyl substances), which are chemicals that have been used in a wide range of consumer and industrial products,” said Miserez. “The amyloid fibrils contain amino acid bonds that trap and sandwich heavy metal particles between them while letting water pass through.”
The researchers say the concentration of heavy metals in contaminated water will determine how much volume of water the membrane can filter out. A hybrid membrane made with sunflower protein amyloids will require only 16kg of protein to filter the equivalent volume of an Olympic-sized swimming pool contaminated with 400 parts per billion (ppb) of lead into drinking water.
Metals recycling
“The process is readily scalable due to its simplicity and minimal use of chemical reagents, pointing towards sustainable and low-cost water treatment technologies,” said Soon. “This allows us to reprocess waste streams for further applications and to fully exploit different industrial food wastes into beneficial technologies."
The trapped metals can also be extracted and further recycled. After filtration, the membrane used to trap the metals can simply be burnt, leaving behind the metals.
“While metals like lead or mercury are poisonous and can be safely disposed of, other metals, such as platinum, have valuable applications in creating electronics and other sensitive equipment,” said Miserez.
“Recovering precious platinum, which costs US$33,000/kg, only requires 32 kg of protein, while recovering gold, which is worth almost US$60,000/kg, only requires 16kg of protein. Considering that these proteins are obtained from industrial waste that is worth less than US$1/kg, there are large cost benefits.”
Low-power
Another big advantage, the researchers say, is that this filtration requires little or no energy, unlike other methods like reverse osmosis that require electricity.
“With our membrane, gravity does most or all of the work,” said Prof Mezzenga. "This low-power filtration method can be very useful in areas where there might be limited access to electricity and power."
"Our work puts heavy metal where it belongs – as a music genre and not a pollutant in drinking water," said Professor Miserez
The researchers are currently exploring the commercial applications of their membrane with BluAct, a spin-off company out of ETH Zurich.
